EA20 Wall fixing collars
Description :
Fixing collars for EA16 duct.
Models
Available in versions with a fixed collar for diameters from 125 mm to 180 mm, and in a multi-diameter version for diameters from 160 mm to 200 mm.
Dimensions Ø 125 - 200 mm
Internal Ø (mm) A (mm) B (mm) C (mm) D (mm) E (mm) F (mm) 125 45 50 30 25 M8 Ø 4,5 160 45 50 30 25 M8 Ø 4,5 180 45 50 30 25 M8 Ø 4,5 160 - 200 23 200 248 225 M8
Price List
The EA20 clamps are fastening components designed to support and secure EA16 series rigid ducts in mechanical ventilation systems. Their construction ensures stable anchoring of the ducts to walls or ceilings, providing ease of installation and long-term reliability.
They are available in both single-diameter and multi-diameter versions. The multi-diameter version allows quick adaptation to different duct sizes and simplifies installation thanks to its adjustable tab.
Thanks to their compatibility with EA16 series rigid ducts, EA20 clamps provide a practical and effective solution for creating neat, safe, and professional air distribution networks in residential, commercial, and light commercial applications.
